General Specifications(詳細說明)：
Winding Type材料………………………………………………… Star
Temperature Rise…………………………………………120℃ electrical angle
Insulation Class…………………………………………B
Ambient Temperature Range…………………………-20℃~+50℃
Insulation Resistance………………………100MΩMin.500VC DC
Dielectric Strength………………………………500V AC 1 minute Electrical Specifications(技術數據): 型號Model | 42BZ40-260-42XG | 42BZ50-260-42XG | 42BZ60-260-42XG | 42BZ80-260-42XG | 42BZ100-260-42XG | 極數Number of Poles | 4 | 4 | 4 | 4 | 4 | 相數Number of Phases | 3 | 3 | 3 | 3 | 3 | 額定電壓 Nominal voltage VDC | 24 | 24 | 24 | 24 | 24 | 額定轉速 Rated speed RPM | 3000 | 3000 | 3000 | 3000 | 3000 | 額定扭矩 Rated Torque N-m | 0.075 | 0.1 | 0.125 | 0.185 | 0.25 | 額定電流 RatedCurrent Amps | 1.3 | 1.9 | 2.4 | 3.5 | 4.7 | 輸出功率 OutputPower Watts | 22 | 31 | 39.2 | 58 | 78.5 | 峰值扭矩Peak Tourque N-m | 0.21 | 0.3 | 0.3 | 0.56 | 0.75 | 峰值電流Peak Current Amps | 4.0 | 5.7 | 7.2 | 10.2 | 14.1 | 力矩常數Torqueconstant N-m/A | 0.06 | 0.06 | 0.06 | 0.06 | 0.06 | 反電勢常數 BackEMF V/kRPM | 2.82 | 2.82 | 2.82 | 2.82 | 2.82 | 轉動慣量 Rotor inertia g·cm2 | 28 | 38 | 48 | 72 | 96 | 電機長度Body Length (L) mm | 40 | 50 | 60 | 80 | 100 | 電機重量 Motor mass kg | 0.3 | 0.4 | 0.45 | 0.65 | 0.8 | 減速箱比速Reducer speed ratio | 一級1:3 1:4 1:5 1:7 1:9 1:10 二級1:15 1:20 1:25 1:40 1:50 | 減速箱長度（L1））Reduction box length mm | 一級43.1mm 二級53.6mm | 減速箱重量Reduction box mass kg | 一級0.2kg 二級0.3kg |
|
